Cast Steel Lift Type Piston Type Check Valve

We specialize in Cryogenic Floating Ball Valve, Monel 400 Globe Valve, Triple Eccentric Wafer Butterfly Valve production and have many years of experience in sales and service of related products so that we can serve customers well and respond quickly to customer needs. We are increasingly expanding our international market share based on quality products, excellent service, reasonable price and timely delivery. We have established and completed a complete quality management system to ensure that all products are processed with high precision in the controlled process, so that the products have traceable quality files. Our success comes from your support and trust. If you give us the order, you will have a satisfactory answer. We sincerely hope to establish a mutually beneficial relationship with you with our high-quality products, reasonable prices and considerate service.

Product Details

NSV Cast Steel Piston check valves(also called Non-return check valve), like all check valves, are used to prevent back flow in the line.that’s operation depend on medium flowing, as this standard valve has no spring in order to minimize cracking pressure and pressure drop, it will only function properly when installed in a horizontal line. Its main role is to prevent the backflow of media, prevent pump and drive motor inversion, and the release of the container media.

Applicable Standard
Design Standard: BS 1868, ASME B16.34, API 6D, DIN2533
Face to Face: ASME B16.10, API 6D, EN 558, DIN 3202
End Flange: ASME B16.5, ASME B16.47, DIN2501, DIN2533
Butt welding Ends: ASME B16.25, DIN3239
Inspection and Test: API 598, DIN3230

Products Range
Size: 2" ~ 24" (DN50 ~ DN600)
Rating: ANSI 150lb-1500lb
Body Materials: Carbon Steel, Stainless Steel, Alloy Steel, Duplex Steel
Trim: Per API 600

Design Features
Bolted cover
Integral seat
Piston type disc design
Flanged or butt welding ends

STRUCTURAL FEATURES

◎ Body-To-Bonnet Joint

Stainless steel + flexible graphite wounded gasket is used for Class150 and Class300 check valve; Stainless steel + flexible graphite wounded gasket is used for Class600 check valve, and joint gasket is also optional for Class600 check valve; Ring joint gasket is used for Class900 check valve; Pressure seal design is used for Class1500～Class2500 check valves.

◎ Body and Bonnet Connection

The body and bonnet of Class150～Class900 check valves are usually with studs and nuts. And the body and bonnet of Class1500～Class2500 check valves are usually of pressure seal design.

FAQ

4. Q: What’s the valves warranty?
A: Our valves warranty period should be 18 months from the date of shipment or 12 months after installation, whichever occurs first.

5. Q:What’s the packing for shipping?

A:Its carton for small valves(sample) and plywood case(don’t to fumigate).

6.Q:Is there have MOQ?

A：No.we can accept 1set,but there have additional cost $150.00(process of export) if the order value within $2000.00

We offer you best value of money and we are ready to develop together with Cast Steel Lift Type Piston Type Check Valve. Our company has a technical team consisting of senior engineers with many years experience in scientific research as well as a well-skilled service team ready to provide satisfactory assistance for customers. With fine quality and excellent technical service, our products enjoy a good reputation not only in domestic market but also in overseas market. We are constantly developing forward-looking products and application technologies.
