Flanged Concentric Disc Butterfly Valve with Gear Operator

We pay attention to the quality, quantity and reasonable price of the products. We guarantee the quality of our Cast Steel Lift Check Valve, Forged Lubricated Plug Valve, Basket Strainers and ensure that the prices are competitive. We have a group of professional and technical personnel, using the most advanced equipment and operating under a mature scientific management system. We effectively implement the production safety responsibility system and enhance the overall safety capability and awareness of the enterprise. With global market competition intensified, in order to enhance the competitiveness, we try to design reasonable scheduling schemes to satisfy demands of customer for diversification and personalization, improve customer satisfaction, shorten production cycle and deliver just-in-time.

Product details

NSV Concentric Butterfly Valve with the advantages of good corrosion resistance, reliable seal, small unsealed moment and so on,the valve body shall be one-piece design with extended neck and a concentric disc and seat configuration to allow for 2” to 48” of piping insulation.

Applicable Standard
Design Standard: API 609, MSS SP-67, MSS SP-68, BS 5155
Face to Face: API 609, ASME B16.10, BS 5155, EN1092
End Connection: DIN PN10/16/25, ANSI B16.1, BS4504
Inspection and Test: API 598

Products Range
Size: 2" ~ 48" (DN50 ~ DN1200)
Rating: PN10,16,150PSI

Body Materials: Ductile Iron,Carbon Steel, Stainless Steel, Alloy Steel, Duplex Steel.
Seat: RUBBER(EPDM,NBR,IIR),PTFE
Operation: Lever, Gear, Electric, Pneumatic, Hydraulic

Design Features
Concentric design
Rubber,PTFE seated
Blow-out proof shaft
Wafer,Lug,Flange Connection
ISO top flange

STRUCTURAL FEATURES

FAQ

1. Q:Do you have any valve in stock?

A:There have a lot of GGC valves(2”&within) in stock,and that can delivery within one week.

2. Q:Do you have customized valve?

A:Yes,we can supply customized valves.

3. Q: What kinds of valves do you manufacture?

A: We usually manufacture valves made of various materials such as cast Iron/ carbon steel,stainless steel,Alloy steel and industrial valves such as ball, gate, globe, check, bellows seal and ETC. For detail information, please refer to "Download>E-Catalog” of homepage.

4. Q:What’s the packing for shipping?

A:Its carton for small valves(sample) and plywood case(don’t to fumigate).

5. Q: How about delivery schedule?

A: Delivery schedule depends on product type. Therefore, please consult with sales team for specific delivery schedule when you inquire quote. The company is making an effort to keep the delivery schedule, which is the promise with customer. The company will improve your satisfaction degree by delivering the necessary product as soon as possible.

After years of development, our products have been trusted by customers. The quality of Flanged Concentric Disc Butterfly Valve with Gear Operator is reliable, and it is in a favorable position among domestic counterparts. Our company is equipped with strong R&D strength and a positive innovation atmosphere. We are dedicated to quality products and consumer support.
