Product details

NSV Lubricated Plug valves Designed for Crude oil, Oil, Natural gas handling and transmission lines. Line sealing is achieved basically by metal to metal contact between body and plug with assistance of sealant injected in between body and plug, which serves both sealing and lubricating during operation.

Considered a high maintenance plug valve, they are often used in applications that have infrequent operations. Lubricated plug valves perform well in processes that utilize fluids which carry mildly abrasive particles such as dirty upstream applications, gas pipeline systems that need bypass valves, and as blow-down valves on valve stations and kicker valves.

Applicable Standard
Design Standard: API 599,6D, ASME B16.34
Face to Face: ASME B16.10
End Flange: ASME B16.5
Butt welding Ends: ASME B16.25
Inspection and Test: API 598, API 6D

Products Range
Size: 2" ~24" (DN50 ~ DN600)
Rating: 150lb ~ 1500LB

Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Duplex Stainless Steel
Plug Material: Carbon Steel, Stainless Steel, Alloy Steel, Duplex Stainless Steel
Seat Material: Metal
Operation : Lever, Gear, Electric, Pneumatic, Hydraulic

Design Features
Reduced port or Full port
Rugged,Heavy-Duty Body
Large port opening

Pressure Balance Lubricates

STRUCTURAL FEATURES

1.Construction of Lubricated Plug Valves
As the name suggests, a lubricated valve uses a lubricant usually made up of a base oil and viscosity improver (like amorphous or fumed silica) that is injected under pressure between the plug face and body seat to reduce friction and seal ports.

2. Hard Surfaced Plug Valves
High Temperature and Abrasive services: For high temperature and abrasive services, NSV plug valve can be supplied with plug taper and body seat hard surfaced with nickel or cobalt base alloys. These materials provides a coating at elevated temperatures. With additional hard surfacing in high erosion areas, hard surfaced valve provides excellent resistance to abrasion in coal, limestone, iron core, copper ore and other water carried slurries. For severe services, hard surfacing extends valve life and improves valve performance significantly.

FAQ

1.Q: What’s the brand of your company can supply ?

A:NSV or OEM service

2.Q:I want to know how to contact the person in charge.

A: When you call representative call number of company(86-577-67378616), sales team will receive your call if there is no special situation. If you let us know your inquiry, we will put you through to the person in charge. If you need a personal phone number, you have to receive it from the person in charge directly after phone call.

3. Q: What’s the valves warranty?
A: Our valves warranty period should be 18 months from the date of shipment or 12 months after installation, whichever occurs first.
4. Q:How can I get a quote?

A: If you request quote by preparing the product spec you want to request specifically through “Contact us or Feedback” of homepage, we will send reply to you ASAP. If the contents of homepage are not available, you can inquire to us via phone(86-577-67378616) or fax(86-577-67372367).

5.Q:Is there have MOQ?

A：No.we can accept 1set,but there have additional cost $150.00(process of export) if the order value within $2000.00.
