Ti C2 Knife Gate Valve with CE ISO API Certificates

Since we have scientific management mode, rigorous working attitude, solid technical strength and advanced manufacturing technology, we can promise that each of our Trunnion Mounted Ball Valves, Forged Lift Check Valve, Plug Valves is of the highest quality. Our company closely connects the development strategy of the company with the pace of China's development, helping the rapid development of the Chinese market and having a place in the world market at the same time. Our company implements 'quality buy-out system' and 'quality accountability system'. For the quality problems, we will check to the end, and we will not let go of any clues. We solemnly promise to all sectors of society that we would like to verify and show our super comprehensive strength through your comprehensive investigation and comparison.

  NSV Titanium Knife gate valve is widely used as a regulating and corrent-carrying device on various fluid pipelines of dregs in large enterprises such as sewage treatment,chemical industry,coal mining industry,paper-making industry,sugar-making industry,tap water,construction,food,electric power,medicine and energy system etc.

• Applicable Standard
  Design Standard: MSS SP-81, ANSI, API, ISO, DIN, EN, JIS etc.
  End Flange: ASME B16.5, ASME B16.47, DIN2533



• Products Range
  Size: 2" to 48"(DN50 to DN1200,larger diameters on request)

• Flange Connection

      EN1092 PN10,PN16,PN25
      ANSI B16.5 (class 125,150)

• Working Pressure

  DN 50 to DN 250: 10 bar

  DN 300 to DN 400: 6 bar
  DN 450: 5 bar
  DN 500 to DN 600: 4 bar
  DN 700 to DN 1200: 2 bar

Materials
Body Materials: Titanium C2,C3,C5,C6,C12(B367 Gr.C2,C3,C5,C6,C12,C7)
Knife Gate: Titanium C2,C3,C5,C6,C12(B367 Gr.C2,C3,C5,C6,C12,C7)

Seat: Soft(EPDM,NBR,PTFE) or Metal Seat
Operation: Handwheel, Gear, Pneumatic, Hydrau-Pneumatic and Electric etc.

Design Features
1. Liftable sealing surface of wedge can scrape of f the adhered things on the sealing surface and automatically eliminate the impurities.
2. The Stainless steel wedge can prevent sealing leakage due to corrosion.
3. The integral stainless steel materials can prevent corrosion and damage.
4. The scientific back seal packing box design makes the bak seal safe, effective and durable.
5. The triangle supporter ensures necessary mechanical properties.

FAQ

1. Q:How can I get your company catalog?

A: For your reference, basic catalogue is same as "Download>E-Catalog” of homepage. If you need printed material or request more specific data like PQ material, please contact sales team.

2. Q:Does your company have any agent/distributor with the exception of China?

A: At present,we have agent in Indonesia,Singapore,Canada,Mexico,Iraq,and welcome contact us if you would like to join us.

3. Q:Does “NSV” valves have supply to any value end user?

A:Yes,,it just like PETROKIMIA GRESIK in Indonesia, BP Iraq,ESFAHAN MOBARAKEH STEEL In Iran etc.

4. Q: I want to be registered as your agency.?

A: Defined inspection and manager’s approval shall be required for being registered as the company’s agency. For specific application method, please consult with sales team. If you are registered as the company’s agency, “Agency Certificate” will be issued.

5. Q:Are you manufacturer or trading company?

A: We’re manufacturer,but our factory name is not named NSV due to we’re professional in promotion NSV brand with best service,and also have sold to many end user success.

'Based on domestic market and expand abroad business' is our progress strategy for Ti C2 Knife Gate Valve with CE ISO API Certificates. Continuously meeting customer needs is our top priority, and we will do our best to guarantee each customer's service requirements. We have built a reliable reputation among many customers.
