PSB Check Valve

  NSV High Pressure with PSC Swing check valves, like all check valves, are used to which allow fluid to flow in one direction but prevent it from flowing in the other, are available in
a wide range of styles. Swing valves, because of their less controlled opening and closing
mechanics, are used in less sensitive applications.

• Applicable Standard
   Design Standard: BS 1868, ASME B16.34, API 6D, DIN2533
   Face to Face: ASME B16.10, API 6D, EN 558, DIN 3202
   End Flange: ASME B16.5, ASME B16.47, DIN2501, DIN2533
   Butt welding Ends: ASME B16.25, DIN3239
   Inspection and Test: API 598, DIN3230


• Products Range
   Size: 2" ~ 24" (DN50 ~ DN600)
   Rating: ANSI 2500lb
   Body Materials: Carbon Steel, Stainless Steel, Alloy Steel, Duplex Steel
   Trim: Per API 600


• Design Features
   Full open design
   PSC(Pressure Seal Cover)
   Swing type disc design
   Renewable or and welded seat
   Flanged or butt welding ends

STRUCTURAL FEATURES

• Advantage&Disadvantage

  The primary benefit of swing check valves is their ability to allow a full, unobstructed flow— which is particularly important in piping systems that may require line cleaning. Swing check valves are also ideal for use in low cost systems with manual valves, such as gate valves in common use.

  Disadvantages include a high rate of wear due to the rotation about the hinge pin and the requirement for full and precise alignment of the disc and seat upon closing. The limitations of this design restrict their use in pulsating systems with intentionally cyclic pressures, as the constant pulsating action of the valve leads to premature wear

FAQ

1. Q:Do you have any valve in stock?

   A:There have a lot of GGC valves(2”&within) in stock,and that can delivery within one week.

2. Q:Do you have customized valve?

A:Yes,we can supply customized valves.

3. Q: What kinds of valves do you manufacture?

A: We usually manufacture valves made of various materials such as cast Iron/ carbon steel,stainless steel,Alloy steel and industrial valves such as ball, gate, globe, check, bellows seal and ETC. For detail information, please refer to " Download>E-Catalog” of homepage.

4. Q:What’s the packing for shipping?

  A:Its carton for small valves(sample) and plywood case(don’t to fumigate).

5.Q: How about delivery schedule?

A: Delivery schedule depends on product type. Therefore, please consult with sales team for specific delivery schedule when you inquire quote. The company is making an effort to keep the delivery schedule, which is the promise with customer. The company will improve your satisfaction degree by delivering the necessary product as soon as possible.
